Heatlink 75108 8 loop 1-1/4 inches ss manifold with flow meters

Product Description

The HEATLINK 75108 is an 8 loop 1-1/4" stainless steel manifold designed for radiant heating systems. It features a supply manifold with a 1" FNPT isolation valve, thermometer, and hose bib/air vent. A lockable 0-2 US gpm visual flow meter allows for precise balancing of flow rates for each loop. The return manifold includes a 1" FNPT isolation valve, thermometer, and hose bib/air vent, with a valve for on/off manual control.

• 2 US gpm flow meters for accurate balancing
• 1" FNPT supply and return isolation valves
• Return valve accepts optional actuators for automated control

Product Highlights

This stainless steel manifold provides precise flow control and isolation for radiant heating loops, featuring integrated thermometers and hose bibs.

Product Information

Standard Information

• Brand: HEATLINK
• Manufacturer Part Number: 75108

Technical Specifications

• Manifold Type: Manifolds
• Construction Material: Stainless Steel
• Trunk Connection Size: 1-1/4"
• Number of Loops: 8
• Supply Manifold Isolation Valve: 1" FNPT
• Supply Manifold Thermometer: Included
• Supply Manifold Hose Bib/Air Vent: Included
• Flow Meter Type: Lockable visual
• Flow Meter Range: 0-2 US gpm (0-7.5 L/min)
• Flow Meter Precision: ±10%
• Return Manifold Isolation Valve: 1" FNPT
• Return Manifold Thermometer: Included
• Return Manifold Hose Bib/Air Vent: Included
• Return Manifold Control Valve: On/off manual control, accepts optional actuators
• Mounting Brackets: Two metal brackets included
