Heatlink 75105 5 Loop 1-1/4 inches SS Manifold With Flow Meters

Product Description

The HEATLINK 75105 manifold is a 1-1/4" stainless steel component designed for hydronic heating systems. It features a supply manifold with a 1" FNPT isolation valve, thermometer, and hose bib/air vent. A lockable 0-2 US gpm visual flow meter allows for precise balancing of flow rates for each of the 5 loops. The return manifold includes a 1" FNPT isolation valve, thermometer, and hose bib/air vent, with valves for manual control and optional actuators.

• 2 US gpm flow meters for precise balancing
• 1" FNPT supply and return isolation valves
• Supply and return hose bibs for convenience

Product Highlights

Stainless steel manifold with integrated flow meters for hydronic system control.

Product Information

Standard Information

• Brand: HEATLINK
• Manufacturer Part Number: 75105
• Country of Origin: ITALY

Technical Specifications

• Type: Manifold
• Material: Stainless Steel
• Trunk Size: 1-1/4"
• Number of Branches: 5
• Trunk Connection Size: 1-1/4"
• Flow Meter Range: 0-2 US gpm (0-7.5 L/min)
• Flow Meter Precision: ±10%
• Isolation Valve Size: 1 inch FNPT
• Pressure Rating: 87 psi
• Mounting Type: Bracket
• Material Standard: ASTM/AISI304 EN10088 1.4306, ASTM B124 C37700, CW614N, CW617N
• Temperature Rating: 32 - 160 deg F
• Includes: (2) Metal Mounting Brackets
