Heatlink 75102 2 loop 1-1/4 inches SS manifold with flow meters

Product Description

The HEATLINK 75102 manifold is a 2 Loop 1-1/4" Stainless Steel Manifold with Flow Meters. It features a supply manifold with a 1" FNPT isolation valve, thermometer, and hose bib/air vent. A lockable 0-2 US gpm (0-7.5 L/min) visual flow meter allows fine-tune balancing of flow rate for each loop. The return manifold includes a 1" FNPT isolation valve, thermometer, hose bib/air vent, and a valve for on/off manual control, accepting optional actuators for automated control.

• 1" FNPT supply and return isolation valves
• 2 US gpm flow meters
• Return valve accepts optional actuators for automated control

Product Highlights

Stainless steel manifold with integrated flow meters for precise loop balancing and automated control readiness.

Product Information

Standard Information

• Brand: HEATLINK
• Manufacturer Part Number: 75102
• Country of Origin: ITALY

Technical Specifications

• Type: Manifolds
• Material: Stainless Steel
• Size: 1-1/4"
• Number of Loops: 2
• Inlet Connection Type: FNPT
• Flow Meter Range: 0-2 US gpm (0-7.5 L/min)
• Flow Meter Precision: ±10%
• Mounting Type: Bracket
• Circuit Flow Rate: 2 gpm
• Material Standard: ASTM B124 C37700, ASTM/AISI 304 EN10088 1.4306
• Measuring Range: 32 to 175 deg F
• Pressure Rating: 87 psi
• Temperature Rating: 32 to 160 deg F
• Number of Outlets: 4
• Circuit Spacing: 8.1 in
• Outlet Center Distance: 1.97 in
