HEATINGVARIOUSMFG-GENERIC 50D50-842 Universal Direct Spark Ignition Control

Product Description

The HEATINGVARIOUSMFG-GENERIC 50D50-842 is a universal direct spark ignition control suitable for various heating systems. This device initiates ignition by generating sparks and activating the gas valve while monitoring the flame sensor for safety. Designed with a complete shut-off feature, it automatically locks out the gas valve if the burner fails to ignite within the designated ignition trial period. The sequence starts when heat is requested by the thermostat, leading to power being routed to the control.

• Features a card port and program keys for customization of ignition timings.
• Accommodates both Direct Sense and Indirect Sense systems.
• Includes an LED indicator for quick diagnostics.

Product Highlights

This control is essential for reliable ignition in heating systems.

Product Information

Standard Information

• Input Voltage: 18 to 30 VAC, 60 Hz
• Current: 0.2 amp + MV at twenty-five degrees Celsius

Technical Specifications

• Relay Contact Ratings: Main Valve Relay: 1.5 amp at twenty-five VAC 60 Hz
• Spark Output: Gap: 0.1 - 0.2, 15kV 25Hz
• Minimum Flame Current for Detection: 2 µA DC
• Operating Temperature Range: Negative forty degrees to one hundred seventy-five degrees Fahrenheit
• Humidity Range: Up to 95% relative humidity (non-condensing)
• Gases Approved: Natural, Manufactured, Mixed, Liquid Petroleum, and LP Gas Air Mixtures
