Heatcraft 2530688S Oem Motor 1/10 hp (1/2 inches Shaft 115V) 2530688S

Product Description

The Heatcraft 2530688S is an Oem 1/10 hp refrigeration motor rated 115 V for evaporator and condenser fan applications. It provides a nominal 1075 RPM and couples to a 1/2 inch shaft for direct replacement in compatible commercial refrigeration equipment. The motor is a single-phase permanent split capacitor design for continuous (S1) duty and supports 50/60 Hz operation with approximately 1.3 A current draw.

• 1/10 hp, 115 V permanent split capacitor (PSC) motor; 50/60 Hz, continuous duty
• Nominal 1075 RPM; 1/2 inch shaft; clockwise (CW) rotation (shaft end view)
• Open enclosure, Class B insulation; approximate current draw 1.3 A; 10.5 inch body length

Product Highlights

OEM replacement motor for Heatcraft refrigeration evaporator and condenser applications

Product Information

Standard Information

• Brand: HEATCRAFT
• Manufacturer Part Number: 2530688S
