HEATCONTROLLERMARS85156 MARS-85156 Greenfield 90 Deg Elbow

Product Description

The HEATCONTROLLERMARS85156 MARS-85156 is a Greenfield 3/4 inch 90-degree elbow fitting used in conduit and flexible metal conduit (FMC) installations. This elbow provides a clean 90-degree directional change for 3/4 inch Greenfield flexible conduit runs. It is a standard trade fitting installed by licensed electricians during wiring rough-in and finish work in both residential and commercial applications. The connector allows protected wiring to navigate corners and bends without stressing conductors or conduit jacket material.

This fitting is suited for flexible metal conduit applications where a 90-degree turn is required at a junction box, panel, or equipment connection point. Typical install scenarios include motor connections, HVAC equipment wiring, and appliance branch circuits where FMC terminates at an enclosure. It is appropriate for use in dry, damp, or locations as permitted by applicable electrical code for FMC connectors of this type.

Key Features

• 90-degree elbow angle for directional changes in conduit runs
• Sized for 3/4 inch Greenfield flexible metal conduit
• Standard FMC elbow connector profile for common trade applications
• Designed for use at equipment, panel, and junction box terminations

Compatibility

Designed as an OEM-style fitting for 3/4 inch Greenfield flexible metal conduit (FMC) terminations in standard electrical conduit installations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits at the panel before making conduit connections at any enclosure or equipment termination. Use the appropriate conduit reamer and fitting wrench to seat and secure the elbow without damaging the conduit jacket. Verify that the connector is listed and appropriate for the installation environment before use.

Technical Specifications

• Conduit Size: 3/4 inch
• Elbow Angle: 90 degrees
• Conduit Type: Greenfield Flexible Metal Conduit (FMC)

Standard Information

• Brand: HEATCONTROLLERMARS85156
• Manufacturer Part Number: MARS-85156
