Heat Controller MCL024AEC30C0PS Heat Pump 2 Ton 265V

Product Description

The HEAT CONTROLLER MCL024AEC30C0PS is a 2-ton horizontal water source heat pump designed for single-phase, 265-volt applications using R-454B refrigerant. It delivers both heating and cooling through a coaxial heat exchanger that transfers energy between the refrigerant circuit and a water loop or ground water source. Rated at 27,500 BTU/h cooling and 24,200 BTU/h heating in ground water mode, with a ground water EER of 23.3 and a COP of 4.4, this unit exceeds ASHRAE 90.1 efficiency standards. Licensed HVAC technicians install and commission this equipment in commercial and residential hydronic system applications.

The MCL024AEC30C0PS is configured for horizontal installation with a left return air option, making it well suited for above-ceiling, chase, or mechanical closet installations where vertical clearance is limited. Its compact footprint is particularly useful in retrofit scenarios where replacing existing horizontal fan coil or water source heat pump equipment without major structural modifications is a priority. The extended-range refrigerant circuit supports performance across a wider entering water temperature range, giving it flexibility in both ground water and water loop system designs. Water loop performance is rated at 24,700 BTU/h cooling at 86 degrees F EWT and 28,800 BTU/h heating at 68 degrees F EWT, with a water loop EER of 14.7 and a COP of 5.0.

Key Features

• Ground water cooling: 27,500 BTU/h at 59 degrees F EWT with EER of 23.3
• Ground water heating: 24,200 BTU/h at 50 degrees F EWT with COP of 4.4
• Water loop cooling: 24,700 BTU/h at 86 degrees F EWT with EER of 14.7
• Water loop heating: 28,800 BTU/h at 68 degrees F EWT with COP of 5.0
• Coaxial heat exchanger with standard heat exchanger option
• Onboard performance monitoring system for early fault detection
• Exceeds ASHRAE 90.1 efficiency standards with R-454B refrigerant

Compatibility

Designed as an OEM horizontal water source heat pump for ground water and closed-loop water loop HVAC systems requiring a 2-ton, single-phase, 265-volt unit with R-454B refrigerant and a left return air configuration.

Installation Notes

Installation must be performed by a licensed HVAC technician with EPA Section 608 certification for R-454B refrigerant handling. Disconnect all electrical power and isolate water supply lines before beginning any installation or service work. Follow local mechanical and electrical codes, including applicable ASHRAE and NEC requirements, for equipment mounting, piping connections, and electrical terminations. Verify entering water temperature, flow rate, and system loop pressure are within the equipment operating range prior to startup.

Technical Specifications

• Nominal Capacity: 2 tons
• Phase: Single-phase
• Voltage: 265 volts
• Refrigerant: R-454B
• Orientation: Horizontal
• Return Air Option: Left
• Heat Exchanger Option: Standard coaxial
• Ground Water Cooling Capacity (59 degrees F EWT): 27,500 BTU/h
• Ground Water EER: 23.3
• Ground Water Heating Capacity (50 degrees F EWT): 24,200 BTU/h
• Ground Water COP: 4.4
• Water Loop Cooling Capacity (86 degrees F EWT): 24,700 BTU/h
• Water Loop EER: 14.7
• Water Loop Heating Capacity (68 degrees F EWT): 28,800 BTU/h
• Water Loop COP: 5.0
• Shipping Weight: 179 pounds
• Shipping Length: 43 inches
• Shipping Width: 20.1 inches
• Shipping Height: 18.3 inches

Standard Information

• Brand: HEAT CONTROLLER
• Manufacturer Part Number: MCL024AEC30C0PS
