Hayward YS10075S Y Strainer 3/4 inches Socket PVC 150 psi

Product Description

The HAYWARD YS10075S Y strainer with a 3/4" socket is made of PVC and has a maximum pressure of 150 psi. It protects piping system components from damage caused by dirt or debris in the process media. It is lightweight and compact and can be mounted in vertical or horizontal positions.

• Pipe Size 3/4 in
• Maximum Pressure at 100 deg F 125 psi
• Includes Screen

Product Highlights

The Hayward Y-strainer is made of PVC plastic, so it will never rust or corrode. It features a heavy-duty hex cap that permits easy removal of the strainer screen for cleaning.

Product Information

Standard Information

• Brand: HAYWARD
• Manufacturer Part Number: YS10075S
• Country of Origin: United States

Technical Specifications

• Item [Specifications]: Y Strainer
• Mesh [Specifications]: 1/32"
• Width [Specifications]: 2"
• Height [Specifications]: 3-3/4"
• Series [Specifications]: YS
• Pipe Size [Specifications]: 3/4"
• Screen Area [Specifications]: 6.91 sq. in.
• Blow Off Port [Specifications]: 3/4 in
• Max. Pressure [Specifications]: 150 psi
• Seal Material [Specifications]: FPM
• Strainer Type [Specifications]: Mesh
• Cv Flow Factor [Specifications]: 6.8 gpm
• Connection Type [Specifications]: socket
• Gasket Material [Specifications]: FPM
• Includes Screen [Specifications]: Yes
• Screen Material [Specifications]: PVC
• Housing Material [Specifications]: PVC
• Maximum Pressure [Specifications]: 125 at 100 Degrees F, 150 psi
• Port 1 Connection Size [Specifications]: 3/4 in
• Port 1 Connection Type [Specifications]: Socket
• Port 2 Connection Size [Specifications]: 3/4 in
• Port 2 Connection Type [Specifications]: Socket
• Port 3 Connection Size [Specifications]: 3/4 in
• Port 3 Connection Type [Specifications]: Socket
• Strainer Connection Type [Specifications]: Push-In Socket Connection
• Maximum Pressure at 100 deg F [Specifications]: 125 psi
• Body Material: PVC
• Basket Material: PVC 1/32 in Perf
• Sealing Material: FPM
• End Connection Type: Socket
• Pressure Rating: 150 PSI
• Cv Coefficient: 6.8000
• Connector Type: Socket
• Thread Size: 0.75 inch
• Size: 3/4-Inch Socket
• A: 4.18 in
• B: 1.69 in
• C: 2.88 in
• D: 2.00 in
• F: 0.81 in
• G: 1.25 in
• H: 2.75 in
• J: 3.00 in
• K: 2.63 in
• L: 7.60 in
• Cv Factor: 6.8
• Model: YS10075S
• Compatible Model: Hayward
• Length: 4-1/8 in
• Blow Off Port: 3/4 in
• Standards: ASTM D1784
• UNSPSC: 40142504
