Hayward W3HS135FDP H-Series Heater 135,000 BTU Propane Gas (Open Line)

Product Description

The Hayward W3HS135FDP is an induced draft heater for above ground pools and spas combining reliable technology with ease of operation and superior performance. This 135,000 BTU gas heater boasts industry-leading hydraulic performance along with easy operation and an environmentally friendly design.

• Available in either natural gas or propane
• Durable cupro nickel heat exchanger
• Industry-leading hydraulic performance with faster speed-to-heat capability

Product Highlights

This Hayward H-Series heater is for above-ground pools and spas. It combines reliable technology with ease of operation and superior performance. It features a cupro nickel heat exchanger and low NOx emissions.

Product Information

Standard Information

• Brand: HAYWARD
• Manufacturer Part Number: W3HS135FDP

Technical Specifications

• Brand: Hayward
• Fuel Type: Propane (LP)
• GTIN: 610377407120
• Heating Capacity (BTU/hr): 135,000
• Hertz: 60 Hz
• Kilowatts: 40 kW
• Low Ambient Operation: Yes
• Maximum Breaker Size (Amps): 15
• Minimum Operating Temperature: 40 00b0F
• Phase - Heaters: 1
• Pool Type: Above Ground
• Product Dimensions: 22.6 " x 21.4 " x 30.3 "
• Product Height: 22.6 in
• Product Length: 30.3 in
• Product Weight: 100 lb
• Product Width: 21.4 in
• Rear Clearance - Heaters: 6"
• Series Heaters: H-Series
• Side Clearance - Heaters: 12"
• Voltage: 120V
• Water Flow Rate Max: 125
• Water Flow Rate Min: 20
• Gas Type: Propane
• Heating Capacity: 135,000 BTU/HR
• Killowatts: 40
• Location: Indoor/Outdoor
• Elevation: 0-9000'
• Ignition: Electronic
• Options: Cupro-Nickel Heat Exchanger
• SKU: W3HS135FDP
• Length: 33.3 in
• Width: 32.8 in
• Height: 30.6 in
• Series: OmniX
