HAYWARD TC1300S 3 PVC True Union Ball Check Valves w/FPM O-Rings

Product Description

The HAYWARD TC1300S is a reliable three-inch PVC True Union Ball Check Valve. It features socket end connections and is designed for both horizontal and vertical installations. This valve operates effectively up to 150 psi and 140 degrees Fahrenheit, making it suitable for various plumbing applications. It has a full port design with a flow rate of 150 gallons per minute and a total inlet to outlet length of 10.56 inches.

• Socket end connections for easy installation
• True union design allows maintenance without disruption
• PVC construction ensures durability and resistance to corrosion

Product Highlights

The TC1300S is ideal for connecting pipes where a reliable, maintenance-free connection is necessary. Its design minimizes back pressure and provides a secure seal with FPM O-rings.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• SKU: HAY TC1300S

Technical Specifications

• Ball Material: PVC
• Body Material: PVC
• Color: Dark Gray
• End Style: Socket
• Flow Rate: 150 gpm
• Inlet to Outlet Length: 10.56 inches
• Nominal Size: 3 inches
• Port Type: Full
• Pressure Rating: 150 psi
• Series: TC Series
• Softgoods Material: FKM
• Temperature Rating: 140 degrees Fahrenheit
• Type: True Union
