HAYWARD TC10075STE 3/4 PVC True Union Ball Check Valve w/EPDM O-Rings

Product Description

The HAYWARD TC10075STE is a 3/4 inch PVC true union ball check valve. This valve is designed for socket and threaded installation. It operates under a pressure rating of 235 psi at a temperature of 70 degrees Fahrenheit. The valve features EPDM softgoods for durability and reliability in various applications.

• True union design allows for easy installation and maintenance.
• Full port design enables maximum flow.
• Applications include water treatment, swimming pools, and chemical processing.

Product Highlights

The TC10075STE valve is effective in preventing backflow in horizontal and vertical installations. It meets industry standards for safety and effectiveness in numerous environments.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• Type: True Union

Technical Specifications

• Body Material: PVC
• Dimensions: 2.63 inches H
• End Style: Socket/Thread
• Inlet to Outlet Length: 4-3/4 inches
• Nominal Size: 3/4 inches
• Port Type: Full
• Pressure Rating: 235 psi
• Series: TC Series
• Softgoods Material: EPDM
• Temperature Rating: 70 degrees F
