HAYWARD TB2300SE 3 CPVC True Union Ball Valve w/EPDM o-rings

Product Description

The HAYWARD TB2300SE is a three-inch CPVC true union ball valve designed for high efficiency and reliability. This valve features EPDM o-rings for secure sealing and socket end connections for easy installation. It is suitable for a variety of applications including water and chemical transfer.

• Constructed with durable CPVC material
• Operates effectively within a pressure range up to 235 psi
• Temperature rated from thirty-four to one hundred eighty degrees Fahrenheit

Product Highlights

The HAYWARD TB2300SE allows for seamless integration into existing plumbing systems.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• UPC: 610377165389

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: CPVC
• Body Material: CPVC
• End Style: Socket
• Inlet to Outlet Length: 10.56 inches
• Nominal Size: 3 inches
• Port Type: Full
• Pressure Rating: 235 psi
• Series: TB Series
• Softgoods Material: EPDM
• Temperature Rating: 34 to 180 degrees Fahrenheit
• Top to Inlet Center: 6.46 inches
• Trim Material: PTFE Seat
