HAYWARD TB2300S 3 CPVC True Union Ball Valve w/FPM o-rings Socket End Connections

Product Description

The HAYWARD TB2300S is a three-inch True Union Ball Valve made from CPVC, designed for reliable use in various fluid applications. This valve features socket end connections and includes FPM o-rings to ensure a good seal. It operates at a pressure rating of two hundred thirty-five psi and can withstand temperatures ranging from thirty-four to one hundred eighty degrees Fahrenheit. The full port design allows for minimal flow restriction, while the T-handle actuator ensures ease of operation.

• Three-inch size with socket end connections
• FPM o-rings for a secure seal
• Full port design for maximum flow

Product Highlights

This valve is NSF Approved and meets Class 23447 per ASTM D1784 standards, making it suitable for a range of plumbing and HVAC applications.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• Nominal Size: 3 in

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: CPVC
• Body Material: CPVC
• End Style: Socket
• Inlet to Outlet Length: 10.56 in
• Port Type: Full
• Pressure Rating: 235 psi
• Softgoods Material: FPM
• Temperature Rating: 34 to 180 deg F
• Top to Inlet Center: 6.46 in
• Trim Material: PTFE Seat
