HAYWARD TB2250S 2-1/2 CPVC True Union Ball Valve w/FPM O-rings

Product Description

The HAYWARD TB2250S is a 2-1/2 inch CPVC True Union Ball Valve designed for efficient flow regulation. This valve features socket end connections and is rated for pressures up to 235 psi. The valve operates in temperatures ranging from thirty-four to one hundred eighty degrees Fahrenheit. Its CPVC construction ensures durability and resistance to corrosion.

• True union design allows for easy installation and maintenance.
• Includes FPM o-rings for secure sealing.
• Full port design for maximum flow.

Product Highlights

This valve is ideal for a range of applications, including water and chemical transfer, making it suitable for various plumbing and industrial settings.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• MPN: TB2250S

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: CPVC
• Body Material: CPVC
• End Style: Socket
• Inlet to Outlet Length: 10.68 inches
• Nominal Size: 2-1/2 inches
• Port Type: Full
• Pressure Rating: 235 psi
• Series: TB Series
• Softgoods Material: FPM
• Temperature Rating: 34 to 180 degrees Fahrenheit
• Top to Inlet Center: 6.46 inches
• Trim Material: PTFE Seat
