HAYWARD TB2150STE 1-1/2 CPVC True Union Ball Valve w/EPDM O-Rings;

Product Description

The HAYWARD TB2150STE is a 1-1/2 inch CPVC True Union Ball Valve designed for reliable performance in various fluid applications. This valve features socket and threaded end connections for ease of installation. The valve is suitable for pressure ratings up to 250 psi and operates effectively within a temperature range of thirty-four to one hundred eighty degrees Fahrenheit.

• Constructed with a CPVC ball for durability.
• Equipped with EPDM O-rings for tight sealing.
• Full port design allows for maximum flow.

Product Highlights

Designed for versatile applications, this valve ensures high performance and longevity in plumbing, irrigation, and industrial systems.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• Product Name: 1-1/2 CPVC True Union Ball Valve

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: CPVC
• Body Material: CPVC
• Nominal Size: 1-1/2 inches
• End Style: Socket/Thread
• Inlet to Outlet Length: 6.85 inches
• Pressure Rating: 250 psi
• Temperature Rating: 34 to 180 degrees Fahrenheit
• Port Type: Full
• Top to Inlet Center: 3.92 inches
• Softgoods Material: EPDM
• Trim Material: PTFE Seat
• Series: TB Series
