HAYWARD TB2150ST 1-1/2 CPVC True Union Ball Valve W/FPM O-Rings Socket/Threaded End Conne

Product Description

The HAYWARD TB2150ST is a CPVC True Union Ball Valve designed for use in various plumbing systems. With a nominal size of one and one half inches, it is suitable for both socket and threaded end connections. This valve is capable of handling pressure up to two hundred fifty psi and operates effectively in temperatures ranging from thirty-four to one hundred eighty degrees Fahrenheit.

• Constructed with durable CPVC material
• Includes FPM o-rings for reliable sealing
• Designed for full port flow

Product Highlights

This ball valve features an actuator-ready T-handle for easy operation and quick adjustment. It meets standards for safety and Quality, ensuring long-lasting performance in demanding applications.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• Model: TB2150ST

Technical Specifications

• Ball Material: CPVC
• Body Material: CPVC
• End Style: Socket/Thread
• Inlet to Outlet Length: 6.85 inches
• Nominal Size: 1-1/2 inches
• Port Type: Full
• Pressure Rating: 250 psi
• Temperature Rating: 34 to 180 degrees Fahrenheit
• Trim Material: PTFE Seat
• Actuator Type: T-Handle
• Softgoods Material: FPM
• Top to Inlet Center: 3.92 inches
