HAYWARD TB2100ST 1 CPVC True Union Ball Valve w/FPM o-rings socket/threaded end connectio

Product Description

The HAYWARD TB2100ST is a one-inch CPVC True Union Ball Valve designed for durability and reliability in various applications. This valve features socket and threaded end connections, making it versatile for different piping systems.

• Media Compatibility: Suitable for gas, oil, and water applications.
• Pressure Rating: Operates under a pressure of up to 250 psi.
• Temperature Range: Safe for use between thirty-two and one hundred ninety degrees Fahrenheit.

Product Highlights

This valve ensures smooth flow control with a full port design and lever-operated actuator, making it ideal for both commercial and residential installations.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• Nominal Size: 1 in

Technical Specifications

• Actuator Type: Lever Operated
• Ball Material: PVC
• Body Material: CPVC
• End Style: Socket x Thread
• Inlet to Outlet Length: 5.44 in
• Media: Gas/Oil/Water
• Orifice Size: 1 in
• Port Type: Full
• Pressure Rating: 250 psi
• Series: TB Series
• Softgoods Material: EPDM/FKM
• Temperature Rating: 32 to 190 deg F
• Top to Inlet Center: 3.32 in
• Trim Material: PVC Stem and PTFE Seat
