HAYWARD TB2075ST 3/4 CPVC True Union Ball Valve w/FPM o-rings; socket/threaded end connect

Product Description

The HAYWARD TB2075ST is a true union ball valve designed for effective flow control in various plumbing and industrial applications. This valve features a three-quarter inch nominal size and a socket/thread end style. It operates under a pressure rating of two hundred thirty-five psi and can handle temperatures ranging from thirty-four to one hundred eighty degrees Fahrenheit.

• Full port design for maximum flow
• Easy to assemble with silicone-free lubricant
• Compatible with actuator systems

Product Highlights

The TB2075ST valve is built with CPVC material ensuring durability in harsh environments. Its PTFE seat trim contributes to the valve's reliability over time.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• UPC: 610377326872

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: CPVC
• Body Material: CPVC
• End Style: Socket/Thread
• Inlet to Outlet Length: 4.85 inches
• Nominal Size: 3/4 inches
• Port Type: Full
• Pressure Rating: 235 psi
• Series: TB Series
• Softgoods Material: FPM
• Temperature Rating: 34 to 180 degrees Fahrenheit
• Top to Inlet Center: 3.02 inches
• Trim Material: PTFE Seat
