HAYWARD TB1250SE 2-1/2 PVC True Union Ball Valve w/EPDM o-rings

Product Description

The HAYWARD TB1250SE is a 2-1/2 inch PVC True Union Ball Valve designed for various piping applications. It features full port flow and socket end connections, allowing for easy installation and maintenance. The valve is rated for 235 psi at seventy degrees Fahrenheit, making it suitable for high-pressure applications.

• Double O-Ring stem seal
• Easy to service and maintain
• Compatible with automated systems

Product Highlights

This ball valve is suitable for water and wastewater treatment, chemical processing, food and beverage industries, and more. Its durable PVC body and EPDM softgoods ensure longevity and reliable performance in various environments.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• UPC: 610377164238

Technical Specifications

• Body Material: PVC
• Inlet to Outlet Length: 10.68 inches
• Nominal Size: 2-1/2 inches
• Orifice Size: 2-3/4 inches
• Port Type: Full
• Pressure Rating: 235 psi
• Series: TB Series
• Softgoods Material: EPDM
• Temperature Rating: 70 degrees Fahrenheit
• Top to Inlet Center: 6.46 inches
• Trim Material: PTFE Seat
