Hayward TB1150STE 1-1/2 PVC True Union Ball Valve w/EPDM o-rings; socket/threaded end conne

Product Description

The Hayward TB1150STE is a 1-1/2 inch PVC True Union Ball Valve designed for reliable performance in plumbing and fluid transfer applications. This valve is ideal for use in various settings, including pools, spas, and other water systems. It features EPDM o-rings for a secure seal and is built to withstand pressures up to 250 psi.

• Socket/threaded end connection for easy installation.
• Full port design allows for maximum flow.
• Compatible with a range of temperatures from thirty-four to one hundred and forty degrees Fahrenheit.

Product Highlights

The Hayward TB1150STE True Union Ball Valve is constructed from durable PVC and includes a T-handle actuator for efficient operation. It meets industry standards for safety and performance.

Product Information

Standard Information

• Manufacturer: Hayward Industrial Products
• Category: Valves

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: PVC
• Body Material: PVC
• End Style: Socket/Thread
• Inlet to Outlet Length: 6.85 inches
• Nominal Size: 1-1/2 inches
• Port Type: Full
• Pressure Rating: 250 psi
• Series: TB Series
• Softgoods Material: EPDM
• Temperature Rating: 34 to 140 degrees Fahrenheit
• Top to Inlet Center: 3.92 inches
• Trim Material: EPDM Seal and PTFE Seat
