HAYWARD TB1100STE 1 PVC True Union Ball Valve w/EPDM O-Rings Socket/Thread

Product Description

The HAYWARD TB1100STE is a one inch PVC True Union Ball Valve designed for durability and ease of use. This valve features socket and threaded end connections, making it suitable for a variety of applications. It operates under a pressure rating of 250 psi and can handle temperatures ranging from thirty-four to one hundred forty degrees Fahrenheit.

• Full port design for maximum flow efficiency
• EPDM O-rings for added sealing strength
• T-handle actuator for easy operation

Product Highlights

This true union ball valve combines functionality with robust construction. It is ideal for use in plumbing systems, irrigation systems, and industrial applications.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• Series: TB Series

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: PVC
• Body Material: PVC
• End Style: Socket/Thread
• Inlet to Outlet Length: 5.44 inches
• Nominal Size: 1 inch
• Port Type: Full
• Pressure Rating: 250 psi
• Softgoods Material: EPDM
• Temperature Rating: 34 to 140 degrees F
• Top to Inlet Center: 3.26 inches
• Trim Material: PTFE Seat
