HAYWARD TB1100ST 1 PVC True Union Ball Valve w/FPM o-rings; socket/threaded end connection

Product Description

The HAYWARD TB1100ST is a true union ball valve made of PVC. It features a socket to threaded end connection and is designed for use with gas, oil, and water. This valve operates under a pressure rating of 250 psi and is suitable for temperatures ranging from thirty-two to one hundred ninety degrees Fahrenheit.

• Full port design allows for maximum flow
• Lever operated actuator for easy operation
• Includes EPDM/FKM softgoods for durability

Product Highlights

This valve is specifically designed for use in plumbing systems where reliability and performance are crucial. The HAYWARD TB1100ST provides durability and efficiency.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• Series: TB Series

Technical Specifications

• Actuator Type: Lever Operated
• Ball Material: PVC
• Body Material: PVC
• End Style: Socket x Thread
• Inlet to Outlet Length: 5.44 inches
• Media: Gas/Oil/Water
• Nominal Size: 1 inch
• Orifice Size: 1 inch
• Port Type: Full
• Pressure Rating: 250 psi
• Temperature Rating: 32 to 190 degrees Fahrenheit
• Top to Inlet Center: 3.32 inches
• Trim Material: PVC Stem and PTFE Seat
