HAYWARD TB1050STE 1/2 PVC True Union Ball Valve w/EPDM o-rings; socket/threaded end connect

Product Description

The HAYWARD TB1050STE is a reliable 1/2 inch PVC True Union Ball Valve designed for effective flow control in various applications. This valve features both socket and threaded end connections for easy installation and maintenance.

• Pressure rated at 250 psi
• Operates within a temperature range of thirty-four to one hundred forty degrees Fahrenheit
• Includes EPDM o-rings for superior sealing performance

Product Highlights

The valve includes a T-handle actuator for smooth operation and full port design for maximum flow.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• UPC: 610377326391

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: PVC
• Body Material: PVC
• End Style: Socket/Thread
• Inlet to Outlet Length: 4.77 inches
• Nominal Size: 1/2 inches
• Port Type: Full
• Pressure Rating: 250 psi
• Series: TB Series
• Softgoods Material: EPDM
• Temperature Rating: 34 to 140 degrees Fahrenheit
• Top to Inlet Center: 2.81 inches
• Trim Material: PTFE Seat
