HAYWARD TB1025T 1/4 PVC True Union Ball Valve w/FPM o-rings

Product Description

The HAYWARD TB1025T is a 1/4 inch PVC True Union Ball Valve with FPM O-rings. Designed for effective flow management, this valve features threaded end connections for secure and easy installation.

• Double O-ring stem seal for improved leak prevention
• Capable of withstanding pressure up to 250 psi
• Constructed with a durable PVC body

Product Highlights

This ball valve is suitable for various applications including water and wastewater treatment, chemical processing, and swimming pool systems.

Product Information

Standard Information

• Manufacturer: HAYWARD INDUSTRIAL PRODUCTS
• UPC: 610377326292

Technical Specifications

• Body Material: PVC
• Nominal Size: 1/4 inch
• Orifice Size: 1/2 inch
• End Style: Thread
• Port Type: Full
• Pressure Rating: 250 psi
• Temperature Rating: 70 degrees F
• Length: 4.77 inches (inlet to outlet)
• Top to Inlet Center: 2.81 inches
• Softgoods Material: FPM
• Trim Material: PTFE Seat
• Series: TB Series
