HAYWARD BYCN1020E1LGB 2 Butterfly Valve PVC Body PVC Disc w/EPDM Liner Lever Operator

Product Description

The Hayward BYCN1020E1LGB is a two-inch butterfly valve designed for various applications. This valve features a PVC body and disc, with an EPDM liner. It includes a lever handle actuator, making it easy to operate. This product is suitable for multiple systems, including potable water, chemical processing, and wastewater treatment.

• Durable PVC construction
• High flow capacity
• Standard lockout handlever

Product Highlights

This valve meets ANSI and NSF standards, ensuring reliability and safety in application.

Product Information

Standard Information

• Manufacturer: Hayward Industrial Products
• Type: Wafer Style

Technical Specifications

• Actuator Type: Lever Handle
• Body Material: PVC
• Disc Material: PVC
• Nominal Size: 2 inches
• Pressure Class: 125 lb
• Temperature Rating: 70 degrees F
• Inlet to Outlet Length: 1-3/4 inches
• Top to Inlet Center: 6.37 inches
• Softgoods Material: EPDM
• Stem & Pin Material: 316 Stainless Steel
• Series: BYCN
