Harvey Tool 944612 Square End Mill 3/16 in 2 Flute Carbide

Product Description

The HARVEY TOOL 944612 is a solid carbide square end mill designed for precise milling operations in metalworking and machining applications. With a 3/16 inch (0.1875 inch) mill diameter and a 9/16 inch (0.562 inch) length of cut, this tool is built for slotting, profiling, and peripheral milling in tight geometries. The 30-degree helix angle promotes efficient chip evacuation and smooth cutting action. An extended reach design with a 1-inch reach length gives machinists access to deeper features without sacrificing rigidity. The bright, uncoated finish makes it suitable for a range of ferrous and non-ferrous materials where coating buildup is a concern.

This end mill is used in precision CNC machining environments, including job shops, toolrooms, and production floors handling close-tolerance work. Its 2-flute configuration is well suited for slotting operations and applications where chip clearance is critical. The single-end, right-hand cutting and right-hand flute direction make it compatible with standard CNC machining centers and manual mills. Machinists working in aerospace, mold and die, or general metalworking will find this a practical choice for small-diameter milling tasks.

Key Features

• 3/16 inch mill diameter with matching 3/16 inch shank diameter for direct collet or end mill holder mounting
• 9/16 inch length of cut suits slotting and pocket milling in shallow to mid-depth features
• 30-degree helix angle supports efficient chip flow and reduced cutting forces
• Centercutting geometry allows direct plunge entry into workpieces
• Extended reach design with 1-inch reach length provides access to recessed features
• Bright, uncoated solid carbide construction for broad material compatibility

Compatibility

Designed as a direct-fit replacement or standard tooling selection for CNC machining centers and manual mills accepting 3/16 inch shank end mills via collet chuck or end mill holder. No specific OEM compatibility was provided for this item.

Installation Notes

Installation should be performed by a qualified machinist familiar with CNC or manual milling equipment. Secure the shank in a properly sized collet or end mill holder and torque the retention mechanism per the toolholder manufacturer specifications. Verify runout with a dial indicator before commencing cuts. Ensure the spindle is fully stopped and the machine is in a safe, locked-out state before changing or inspecting tooling.
