Harvey Tool 72062-C3 Square End Mill 1/16 in 2 Flute Carbide

Product Description

The HARVEY TOOL 72062-C3 is a miniature solid carbide square end mill designed for precision material removal in demanding machining applications. With a 1/16-inch (0.0625-inch) cutting diameter and a 0.186-inch length of cut, it is engineered for fine-detail work in tight geometries. The AlTiN coating improves heat resistance and extends tool life in abrasive materials. At 1-1/2 inches overall length with a 1/8-inch shank diameter, this end mill fits standard collet systems and is suited for use on CNC machining centers and high-speed spindles. Licensed machinists and CNC operators are the typical end users.

This end mill is built for cutting steel, stainless steel, cast iron, aluminum and non-ferrous metals, and CFRP materials. The stub-and-standard length profile from the Miniature End Mills series makes it a practical choice for slotting, profiling, and contouring in small-feature work where tool deflection must be minimized. It is a single-end, centercutting tool, so it can plunge directly into the workpiece. Right-hand cut and right-hand flute direction are standard for conventional CNC setups.

Key Features

• Solid carbide construction for rigidity and wear resistance in hard materials
• AlTiN coating for elevated heat resistance and extended tool life
• 2-flute, 30-degree helix geometry promotes chip evacuation in slotting and profiling
• Centercutting design allows direct plunge entry without a pre-drilled pilot hole
• Right-hand cut, right-hand flute — compatible with standard CNC spindle rotation
• 1/8-inch shank diameter fits common ER collets and miniature toolholders

Compatibility

Rated for use in steel, stainless steel, cast iron, aluminum and non-ferrous metals, and CFRP materials (ISO material codes P, M, K, N, and C). Fits any toolholder or collet accepting a 1/8-inch shank diameter.

Installation Notes

Installation is performed by CNC machinists or tool-and-die professionals. Ensure the spindle is fully stopped and the machine is in a safe state before changing tooling. Seat the shank fully into the collet or toolholder and torque the retention nut per the toolholder manufacturer specification. Verify runout with a dial indicator before cutting, as excessive runout on small-diameter end mills accelerates wear and increases breakage risk.
