Harvey Tool 23907-C3 O-Ring Dovetail Cutter 0.0550 in Diameter 1-1/2 in Overall Length

Product Description

The Harvey Tool 23907-C3 is a carbide dovetail cutter designed for precision milling. This tool features a diameter of 0.0550 inches and an included angle of forty-eight degrees, making it suitable for creating half and full dovetails without drop hole allowance. The cutter is made from high-performance carbide and is coated with AlTiN for enhanced durability and cutting performance.

• Solid carbide construction for durability
• Designed for milling applications with no drop hole allowance
• Suitable for non-ferrous materials, stainless steel, and composites

Product Highlights

This cutter is ideal for applications requiring a precise dovetail profile. It mills a bottom radius and is effective in various materials including metal and composites.

Product Information

Standard Information

• Brand: Harvey Tool
• MPN: 23907-C3

Technical Specifications

• Diameter: 0.0550 inches
• Shank Diameter: 0.1250 inches
• Overall Length: 1.5000 inches
• Number of Teeth: 2
• Corner Radius: 0.0150 inches
• Flutes: 2
• Double Ended: Yes
• Angle: 48 degrees
• Neck Diameter: 0.0230 inches
• Profile: Dovetail
