Harvey Tool 17118-C3 Corner Rounding End Mill 5/16 in Dia Cutter 2-1/2 in OAL

Product Description

The Harvey Tool 17118-C3 Corner Rounding End Mill offers precision milling with a cutter diameter of five sixteenths inches and an overall length of two and a half inches. This tool is made from solid carbide and features an AlTiN coating for improved durability and performance. It has two flutes and a right-hand cutting direction, making it ideal for various materials such as non-ferrous metals, cast iron, steel, and stainless steel.

• Diameter: 0.3125 inches
• Overall Length: 2.500 inches
• Tip Diameter: 0.0580 inches

Product Highlights

This end mill is designed for corner rounding, making it efficient for producing precise curves and smooth edges. The double-ended design increases tool life and versatility in operations.

Product Information

Standard Information

• Brand: Harvey Tool
• Material: Solid Carbide

Technical Specifications

• Coating: AlTiN
• Diameter: 0.3125 inches
• Shank Diameter: 0.3125 inches
• Overall Length: 2.500 inches
• Flutes: 2
• Cutting Direction: Right Hand
• Length of Cut: 0.123 inches
• Radius: 0.118 inches
