Harvey Tool 13985-C3 Square End Mill 0.085 in 2 Flute Altin

Product Description

The HARVEY TOOL 13985-C3 is a solid carbide square end mill designed for precision milling in ferrous and non-ferrous materials. With a 0.085-inch cutting diameter and a 0.127-inch length of cut, this tool is built for tight-tolerance work in confined pockets and slots. The AlTiN coating provides high heat resistance and extends tool life in demanding cutting conditions. A 30-degree helix angle promotes smooth chip evacuation and reduces cutting forces. This end mill is single-end and centercutting, making it suitable for plunge entry as well as side milling. It is installed and run by machinists and tool-and-die professionals in CNC milling applications.

This end mill is suited for small-feature machining in mold making, die work, and precision part production. The 0.125-inch shank diameter fits standard 1/8-inch collet chucks and tool holders. The 1.5-inch overall length keeps deflection low when working in shallow-to-medium depth applications. Right-hand cutting and right-hand flute direction make it compatible with conventional CNC spindle setups. The AlTiN coating makes it a strong candidate for dry or semi-dry cutting in hardened steels and stainless alloys where heat buildup is a concern.

Key Features

• Solid carbide construction for rigidity and wear resistance in demanding materials
• AlTiN coating for high-temperature performance and extended tool life
• Centercutting geometry allows direct plunge entry into workpiece
• 30-degree helix angle promotes efficient chip evacuation
• Right-hand cut and right-hand flute direction for standard CNC spindle compatibility
• 0.125-inch shank fits standard 1/8-inch collet tool holders

Compatibility

Designed for use in CNC machining centers and milling machines equipped with 1/8-inch collet or end mill holders accepting a 0.125-inch shank diameter.

Installation Notes

Installation should be performed by a qualified machinist. Ensure the spindle is fully stopped and the machine is powered down before changing tooling. Seat the shank fully and evenly in the collet or tool holder to the recommended insertion depth before tightening. Follow the tool manufacturer and machine builder guidelines for runout tolerance, speed, and feed rates appropriate to the workpiece material and coating type.
