Hartmann Controls PRS-TDM-MECH 2 Door Expansion Module

Product Description

The HARTMANN CONTROLS PRS-TDM-MECH two-door module with mechanical relays expands door/reader/input/output capacity on the PRS-2DR Starter. Ideal for installs or retrofits where power supplies and wiring are pre-existing. Up to 4 can be added within a single PRS-Door controller for a maximum of 8 doors.

• Power: 12VDC power is provided from the PRS-Master controller via interconnect strips. Can be externally powered.
• Communication: RS-458 communication between PRS-Master and TDM expansion panels.
• Outputs: 4 mechanical relays with N/O and N/C outputs, each capable of switching up to 5A, 30VDC or 35VAC, and 2 SSR relays capable of switching 1A, 30VDC or 30VAC.

Product Highlights

Expands door capacity with mechanical relays, ideal for retrofits with pre-existing wiring.

Product Information

Standard Information

• Brand: HARTMANN CONTROLS
• Manufacturer Part Number: PRS-TDM-MECH

Technical Specifications

• Power: 12VDC from PRS-Master controller or external power
• Communication: RS-458 between PRS-Master and TDM expansion panels
• Outputs: 4 mechanical relays (5A, 30VDC/35VAC) and 2 SSR relays (1A, 30VDC/30VAC)
• Inputs: 6 Digital or Supervised inputs
• Relay Type: Mechanical
