Hartell 806029 A3X-115 Condensate Pump 115V (1 gal tank)

Product Description

Hartell 806029 is a commercial-grade A3X-115 condensate pump rated for 115V operation and high-temperature condensate up to 212°F. It provides fully automatic condensate removal using a 1 gallon reservoir and a 1/10 HP motor, with flow capacity up to 351 gal/h and a maximum head of 30 ft. The pump includes a stainless steel shaft, die-cast aluminum impeller, built-in check valve, reversible reservoir and is plenum rated to UL 2043.

• 115V operation, 1/10 HP motor, 1 gallon tank, flow up to 351 gal/h and 30 ft max head
• High-temperature capability to 212°F; stainless steel shaft and die-cast aluminum impeller
• Fully automatic operation with built-in check valve, quick-disconnect discharge, reversible reservoir and auxiliary switch

Product Highlights

Commercial high-temperature condensate pump, plenum rated (UL 2043), 115V, 1 gal capacity, 351 gal/h flow, includes auxiliary switch

Product Information

Standard Information

• Brand: HARTELL
• Manufacturer Part Number: 806029
• Country of Origin: USA

Technical Specifications

• Brand: Hartell
• MPN: 806029
• Model: A3X-115
• Manufacturer Catalog Number: 20895
• Voltage: 115 V
• Power Source: Corded electric
• Motor Power: 1/10 hp
• Flow Rate: 351 gal/h
• Tank Capacity: 1 gal
• Maximum Condensate Temperature: 212°F
• Max Head: 30 ft
• Auxiliary Switch: Yes
• Operation: Fully automatic
• Materials: Stainless steel shaft; die cast aluminum impeller
• Built-in Check Valve: Yes
• Discharge Connections: A3: 3/8 inch copper compression; A5: 1/2 inch copper compression
• Quick-disconnect Discharge: Yes
• Reversible Reservoir: Yes
• Plenum Rating: UL 2043
• UL Recognition: Component recognized
• Dimensions (L x W x H): 12 in x 6 in x 10.5 in
• Weight: 11 lbs
• Country of Origin: USA
