Hart Cooley 672m2020w Steel Return Air Grille 20x20 White

Product Description

The HART COOLEY 672m2020w is an all-steel return air grille designed for residential and light commercial HVAC systems. Measuring 20 inches by 20 inches, it features fins spaced at 1/2 inch intervals and set at a 40-degree angle to maximize free area while maintaining airflow performance. The 5/16-inch margin turnback provides a clean, flush fit against the wall or ceiling surface. A bright white powder finish gives it a finished look suitable for visible interior installations. HVAC technicians and general contractors install this grille as part of forced-air return air systems.

This grille is used in return air applications for residential and light commercial forced-air systems. It is installed at wall, floor, or ceiling return openings where a fixed-blade, non-dampered grille is appropriate. The 20-inch by 20-inch face size accommodates common residential return duct openings. Its steel construction makes it suitable for standard interior environments where durability and a clean appearance are both priorities.

Key Features

• All-steel construction for durability in return air applications
• 1/2-inch fin spacing set at 40 degrees for high free area and efficient airflow
• 5/16-inch margin turnback for a clean, flush wall or ceiling installation
• Bright white finish suitable for visible interior return air locations
• Fixed-blade design — no moving parts to adjust or maintain

Compatibility

Designed as an OEM-style fixed-blade return air grille for standard residential and light commercial forced-air duct systems with a 20-inch by 20-inch return air opening.

Installation Notes

Installation is typically performed by an HVAC technician or general contractor as part of a forced-air duct system. Power down the air handling equipment before working near the return air opening. Secure the grille to the surrounding wall, ceiling, or floor surface using fasteners appropriate to the substrate. Verify the duct opening dimensions before installation to ensure proper fit and seal.

Technical Specifications

• Face Size: 20 inches x 20 inches
• Material: Steel
• Fin Spacing: 1/2 inch
• Fin Angle: 40 degrees
• Margin Turnback: 5/16 inch
• Finish: Bright White
• Unit of Measure: Each

Standard Information

• Brand: HART COOLEY
• Manufacturer Part Number: 672m2020w
