Product Description
The HART & COOLEY 502160 8TLCRS all fuel adjustable roof support is designed for use with all fuel TLC chimney vent pipes. It may be used on a roof and adjusts to any roof pitch. It can also be used above an offset to support it, or as a supplementary support when the chimney height exceeds that of the primary support. Supports a total of 30 feet of chimney with up to 20 feet below support.
- The Roof Support May be Used on a Roof and Adjusts to any Roof Pitch
- It May be Used above an Offset to Support the Offset or as a Supplementary Support when the Chimney Height Exceeds that of the Primary Support
- Supports a Total of 30 Feet of Chimney with up to 20 Feet below Support
Product Highlights
The roof support is adjustable and can be used in multiple configurations for chimney support.
Product Information
Standard Information
-
Brand: HART & COOLEY
-
Manufacturer Part Number: 502160
-
Country of Origin: Domestic
Technical Specifications
-
Manufacturer: Hart & Cooley
-
Manufacturer Part Number: 502160
-
Manufacturer Part Number Additional: 8TLCRS
-
UPC: 699663008173
-
Applicable Standard: UL 103
-
Application: For all fuel TLC chimney vent pipe
-
Brand: Hart & Cooley
-
Material: Steel;304 Stainless Steel
-
Model: 8TLCRS
-
Size: 8 in
-
Standards/Approvals: UL Listed
-
Type: Adjustable
-
Diameter: 10in
-
End to End Dimension: 19in
-
Suitable For Use With: Model TLC All-Fuel Chimney
