HART & COOLEY 102700001 Air Filter 10 inches x 20 inches x 1 inches MERV 8

Product Description

The HART & COOLEY 102700001 is an air filter designed to fit in spaces measuring ten inches by twenty inches by one inch. It features a MERV 8 rating, which indicates its effectiveness in trapping dust and allergens. This filter is built with an innovative multi-pleat design, utilizing a unique blend of specialized synthetic fibers for high performance.

• Size: 10 inches x 20 inches x 1 inch
• Moisture-resistant beverage board frame for durability
• 100% mechanical filtration for efficient dust capture

Product Highlights

This filter is suitable for residential and commercial HVAC systems, helping to improve air quality by reducing airborne particles.

Product Information

Standard Information

• Product Type: Replacement Filter
• Size: 10 inches x 20 inches x 1 inch

Technical Specifications

• Filter Type: Pleated
• Actual Size: nine and one-half inches x nineteen and one-half inches x three-quarters inch
• Air Flow Capacity: 425 cfm, 700 cfm
• Depth: 1 inch
• Frame Material: Beverage Board
• Height: 20 inches
• Initial Resistance: 0.21 inches, 0.26 inches
• MERV: 8
• Media Area: 2.3 square feet, 2.9 square feet
• Rated Velocity: 300 fpm, 500 fpm
• Temperature Rating: 200 degrees F
• Width: 10 inches
• Pleats Per Linear Feet: 15
• Media: Synthetic
