Harris Product Group 3302214 Model 9200 Heavy-Duty Regulator Oxygen 0 to 125 psig 3000 psig Inlet CGA 540

Product Description

The Harris Product Group 3302214 Model 9200 Heavy-Duty Regulator is designed for oxygen applications. It operates with a flow range of zero to 125 psig and has a maximum inlet pressure of 3000 psig. The regulator is fitted with a CGA 540 inlet connection, making it suitable for standard oxygen tanks and systems.

• Suitable for laboratory, industrial, and welding use.
• Features neoprene diaphragms for reliable performance.
• Equipped with a self-reseating relief valve for added safety.

Product Highlights

This regulator ensures a constant delivery pressure across varying inlet pressures, ideal for consistent gas flow in various applications.

Product Information

Standard Information

• Manufacturer: Harris Product Group
• Country of Origin: US

Technical Specifications

• Flow Range: 0 to 125 psig
• Gas Type: Oxygen (O2)
• Gauge Size: 2.5 in
• Inlet Connection: CGA 540
• Inlet Pressure [Max]: 3000 psig
• Outlet Connection: 9/16 in-18 RH
• Outlet Pressure [Max]: 125 psig
• Series: Model 9200
