Hammond PH250MGJ Control Transformer 250VA

Product Description

The HAMMOND PH250MGJ is a 250VA control transformer designed for use in industrial and commercial control circuits. Control transformers step down line voltage to a lower control voltage, providing stable, isolated power to relays, solenoids, pilot lights, and other control-circuit loads. The PH250MGJ is suited for panel builders, electricians, and HVAC controls technicians who need a reliable transformer for low-voltage control applications. At 250VA, it offers enough capacity to support multiple simultaneous control loads in a single panel.

This transformer is used in commercial and industrial electrical panels, motor control centers, and HVAC control systems where a dedicated low-voltage control supply is required. It is typically installed during panel assembly or during retrofit work on existing control circuits. Electricians and controls technicians are the primary installers for this type of component.

Key Features

• 250VA capacity supports multiple control-circuit loads simultaneously
• Provides isolated low-voltage output for relay, solenoid, and pilot light circuits
• Designed for industrial and commercial control panel applications
• Compact form factor suitable for DIN rail or panel mounting configurations

Compatibility

Designed as an OEM-style replacement or new-installation control transformer for commercial and industrial low-voltage control circuit applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements. Disconnect and lock out all power to the panel before removing or installing the transformer. Verify that the primary voltage matches the available supply voltage and that the secondary VA rating meets or exceeds the total connected control load before energizing. Do not exceed the rated 250VA capacity of the transformer.

Technical Specifications

• VA Rating: 250VA
• UPC: 80342307855

Standard Information

• Brand: HAMMOND
• Manufacturer Part Number: PH250MGJ
