Hammond 1435c Pushbutton Enclosure Nema 12 13 Steel Gray

Product Description

The HAMMOND 1435c is a mild steel pushbutton enclosure from the 1435 Series, designed to house up to three 30.5mm pilot devices including pushbuttons, selector switches, and pilot lights. Built to NEMA 12 and NEMA 13 ratings with IP54 protection, it guards against dirt, dust, oil, and water ingress — making it well suited for industrial and commercial electrical control applications. The enclosure measures 8 inches by 3.25 inches by 2.75 inches and features a powder coat finish over a phosphatized substrate in ANSI 61 gray. Certifications include UL 508, CSA, CE, and JIC EGP-1. Licensed electricians and industrial control panel builders are the primary installers.

This enclosure is used in industrial facilities, manufacturing environments, and commercial buildings where control stations must withstand exposure to oil, coolants, dust, and non-corrosive liquids. It is sized for three device holes arranged in a single vertical row, each 1.21 inches in diameter to accept standard 30.5mm devices. Typical applications include operator control stations for motors, conveyors, machinery, and process equipment where NEMA 12 or NEMA 13 environmental protection is required.

Key Features

• NEMA 12 and NEMA 13 rated enclosure with IP54 protection against dust and oil
• Three device holes in a single vertical row, each 1.21 inches in diameter for 30.5mm devices
• Powder coat over phosphatized steel provides a durable, corrosion-resistant finish
• Captive cover screws thread into sealed wells to maintain enclosure integrity
• Oil-resistant gasket with adhesive backing ensures reliable sealing at the cover
• Bonding stud on the door and grounding stud on the enclosure body included
• Welded mounting brackets for direct wall installation

Compatibility

Designed to accept standard 30.5mm pilot devices including pushbuttons, selector switches, and pilot lights conforming to IEC 60529. Part of the Hammond 1435 Series of mild steel pushbutton enclosures.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits and lock out power at the source before mounting or wiring the enclosure. Use the provided welded bracket for secure wall mounting and verify the grounding stud connection meets local bonding requirements. Confirm the installed gasket seats evenly around the cover perimeter before securing cover screws to maintain the rated environmental protection.
