Product Description
The Halo RA56LS9FSD2W1EWH RA Baffle Adjustable Recessed LED Trims are designed for 5" or 6" recessed housings. Operating at 120V and 8.8 W, they offer selectable lumens (600 or 1000) and CCT (2700K, 3000K, 3500K, 4000K, or 5000K). The adjustable gimbal tilts up to 35 degrees and rotates 360 degrees. Ideal for retrofit, remodel, and new construction applications.
- 5"/6" LED trims
- Adjustable gimbal tilts up to 35° and rotates 360° to aim light where it's needed
- 6-Position Switch: 5-Color Field-SeleCCTable warm white to daylight (2700K, 3000K, 3500K, 4000K, 5000K) + Dim-to-Warm (3000K dims to 1800K)
Product Highlights
Adjustable recessed LED trims with selectable lumen and color temperature options. Ideal for sloped ceilings, task lighting, or wall washing applications.
Product Information
Standard Information
-
Brand: HALO
-
Manufacturer Part Number: RA56LS9FSD2W1EWH
-
Country of Origin: CN
Technical Specifications
-
Type: Baffle Adjustable Recessed
-
Series: RA
-
Lamp Type: LED
-
Lens Type: Impact-Resistant Polycarbonate
-
Manufacturer: Cooper Lighting Solutions
-
Mounting Type: Recessed
-
Enclosure Type: Air-tite, IC-rated, damp rated, and ENERGY STAR® certified
-
Voltage Rating: 120 V
-
Amperage Rating: 0.07 @ 120V A
-
Fixture Wattage: 8.8 W
-
Color Temperature: Selectable, 2700K, 3000K, 3500K, 4000K, 5000K CCT
-
Recessed Trim Type: Baffle
-
Lighting Technology: LED
-
Color Rendering Index (CRI): 90 CRI
-
Brand: HALO
-
Size: 5 in and 6 in
-
Wattage: 7 watts
-
Material: Aluminum
-
Style: Modern
-
Light fixture form: Recessed
-
Room Type: Bedroom, Home Office, Kitchen, Living Room
-
Specific Uses For Product: Home
-
Indoor Outdoor Usage: Indoor
-
Power Source: Corded Electric
-
Other Special Features of the Product: Dimmable
-
Light Source: LED
-
Number of Light Sources: 1
-
Light Color: White (adjustable from 2700K to 5000K)
-
Lighting Method: Downlight
-
Brightness: 600-900 Lumen
-
Mounting: Recessed
-
Fixture Type: Recessed
-
Installation Type: Recessed Ceiling Mount
-
Specification Met: Energy Star
-
Light Fixture Installation Location: ceiling
-
Model Number: RA56LS9FSD2W1EWH
-
Model Name: RA Recessed Adjustable Retrofit LED
-
Item Type Name: Recessed Adjustable Gimbal Integrated LED Retrofit
-
Category: 5"/6" LED Trims
-
Nominal Size (in.): 5 in,6 in
-
Occasion: New Home, Casual
-
Sensor Type: Light
-
Era: 21st Century (2000-now)
-
Light Direction: Downwards
-
Installation Area: Indoor
-
Year Manufactured: 2023
-
Control Style: Switch, Dimmer, See description, Wall Switch, Dimmer
-
Shade Shape: Round
-
Finish: Matte
-
Room: Cloakroom, Bathroom, Dining Room, Bedroom, Attic, Utility/Laundry Room, Living Room, Sunroom, Home Office/Study, Workshop, Bar, Kitchen, Garage, Entryway, Porch, Closet, Den, Foyer, Study
-
IP Rating: IP20
