Product Description
The Halo HU1118D9SMB under cabinet lighting features an integrated 8W LED lamp with a 120 VAC power supply. This surface-mounted light has an aluminum housing with a matte black finish. It emits 560 lumens with a selectable color temperature of 2700/3000/4000 K and a CRI of 90. Ideal for task, accent, office, cove and utility, under and above cabinet lighting display.
- Dimmable down to 5% with select 120 V dimmers
- Multiple wiring options including flexible conduit, romex or plugin
- Specialized optical system consisting of tightly clustered proximity phosphor LEDs, advanced optical chamber coatings and lens materials resulting in soft illumination with high efficiency
Product Highlights
The Halo HU1118D9SMB offers energy savings and easy installation with multiple wiring options and dimming capabilities.
Product Information
Standard Information
-
Brand: HALO
-
Manufacturer Part Number: HU1118D9SMB
-
Country of Origin: China
Technical Specifications
-
Type: Integrated
-
Lumens: 560 Lumens
-
Lamp Type: LED
-
Light Output: 60 Lumens/W
-
Manufacturer: Cooper Lighting Solutions
-
Mounting Type: Surface
-
Housing Finish: Matte Black
-
Voltage Rating: 120 VAC
-
Amperage Rating: 0.067 A
-
Fixture Wattage: 8 W
-
Housing Material: Aluminum
-
Color Temperature: 2700/3000/4000 K
-
Color Rendering Index (CRI): 90
-
Sub Brand: HU11 LED SeleCCTable™ Under Cabinet
-
Application: Lighting
-
Mounting: Under Cabinet
-
Special Features: 3 selectable color temperatures: 2700K, 3000K and 4000K, 90 CRI
-
Standard: cULus Listed;Damp Locations Listed;Energy Star Certified;Title 24 Compliant
-
Item Type: Surface
-
Wattage: 8 W
-
Power Factor: >0.9
-
Includes: Conduit Connector and Romex Strain Relief Hardware, LED Bulb
-
Environmental Conditions: Damp Location
-
Dimmable: Yes
-
CRI: 90.0000
-
Construction: Extruded Aluminum
-
Driver Type: ELV/Triac Dimming to 5%
-
Collection: SeleCCTable™
-
Brand Name: Halo
-
Series: HU11 Series
