Product Description
The Halo H5RICAT is a recessed lighting housing designed to accommodate PAR20 and PAR30 halogen lamps. The H5 series allows for varied lighting effects with one basic housing. The H5RICAT is suitable for applications needing inconspicuous lighting in existing ceilings and meets restricted airflow requirements. Includes remodel clips and a junction box.
- Features QuickConnect wiring connectors in junction box
- Thermally protected die-formed housing
- Remodel springs accommodate 1/2 and 5/8 in ceiling material
Product Highlights
The Halo H5RICAT recessed lighting housing is an air-tite housing suitable for PAR20 and PAR30 halogen lamps, ideal for remodel applications.
Product Information
Standard Information
-
Brand: HALO
-
Manufacturer Part Number: H5RICAT
-
Country of Origin: Mexico
Technical Specifications
-
Type: Line Voltage Remodel
-
Depth: 6-1/8 in
-
Series: H5 Series
-
Width: 6.15 in
-
Diameter: 5 in
-
Height: 8.35 in
-
Lamp Type: PAR20/PAR30 Halogen
-
Manufacturer: Cooper Lighting Solutions
-
Mounting Type: Ceiling
-
Voltage Rating: 120 VAC
-
Ceiling Opening: 5-1/2 in
-
Insulation Type: IC
-
Number of Lamps: 1
-
Housing Material: Aluminum
-
Suitable For Use With: Halo Recessed Downlight Fixture
-
Wattage: 75 Watt
-
Amperage: 0.625 Amp
-
Sub Brand: H5RICAT Series
-
Applications: Lighting
-
Ballast Type: N/A
-
ARRA Compliant: Yes
-
Standard: UL/cUL Listed - Wet Location;IC Rated;Airtite
-
Item Type: 5" H5 Housing
-
Cutout Size: 5-1/2 Inch
-
Construction: Die Stamped 20 Gauge Aluminum
-
Brand Name: Halo
-
Item Name: Recessed Remodel Housing
-
Standards: UL/cUL 1598 Listed
-
Component Type: Housing
-
Trim Size: 5 Inch
-
Lamp Included: No
-
Ceiling Type: Insulated, Air-Tight
