Product Description
The HALO H36RTAT is a Non-IC AIR-TITE™ remodel fixture for use with H3 3. series trims. It is Air-Tite rated to prevent airflow between heated or air conditioned spaces and unconditioned attic areas. Designed for installation from below the ceiling and uses 120V GU10 lamps. Insulation must be kept 3 inches away from all sides of housing.
- Slide-N-Side™ wire traps
- Quick Connect wiring connectors included in junction box
- AIR-TITE™
Product Highlights
The Halo H36RTAT is a 3" Non-IC Air-Tite remodel housing designed for use with H3 series trims and GU10 lamps. It prevents airflow and is suitable for 120V line voltage applications.
Product Information
Standard Information
-
Brand: HALO
-
Manufacturer Part Number: H36RTAT
-
Country of Origin: Mexico
Technical Specifications
-
Type: 3" H3 Housing
-
Brand: Halo
-
Width: 3.0 in
-
Finish: Raw Finish
-
Voltage: 120 Volt
-
Amperage: 0.417 at (120V)
-
Diameter: 3 Inch
-
Material: Steel
-
Sub Brand: H36RTAT Series
-
Applications: Lighting
-
Aperture Size: 3 in
-
Mounting Type: Recessed
-
ARRA Compliant: Yes
-
Number of Lamps: 1
-
Lamp Type: GU10
-
Housing Type: Non-IC AIR-TITE™ remodel
-
Size: 3 Inches
-
Model / MPN: H36RTAT
-
Manufacturer: Cooper Lighting Solutions
-
Aperture: 3 Inch
-
Voltage Rating: 120V
-
Wattage: N/A
