Halex 35600 Beam Clamp 1 in Malleable Iron Threaded Rod

Product Description

The HALEX 35600 is an electroplated malleable iron beam clamp designed to secure threaded rod to structural steel beams in mechanical, electrical, and plumbing support systems. The clamp accepts 1/4-inch threaded rod and provides a reliable anchor point for suspended pipe hangers, conduit supports, and equipment mounting assemblies. The electroplated finish adds corrosion resistance for typical interior installation environments. At 0.188 pounds per unit, it is a lightweight yet durable fastener suited for overhead support work performed by electricians, pipefitters, and mechanical contractors.

This beam clamp is used in commercial and light industrial construction where threaded rod suspension systems are required. It is appropriate for attaching to the lower flanges of I-beams, H-beams, and similar structural members. The base measures 1 inch wide by 1.25 inches deep, making it compatible with standard beam flange thicknesses encountered in typical structural steel framing. It is sold individually and is well suited for both new construction rough-in and retrofit support installations.

Key Features

• Malleable iron construction for strength and durability in overhead support applications
• Electroplated finish provides corrosion resistance in interior environments
• Accepts 1/4-inch threaded rod for standard suspension assemblies
• Base size of 1 inch wide by 1.25 inches deep fits common structural beam flanges
• Lightweight at 0.188 pounds per clamp for easy handling during overhead installation

Compatibility

Designed for use with 1/4-inch threaded rod in standard beam-flange suspension systems on structural steel I-beams and H-beams in commercial and light industrial applications.

Installation Notes

Installation is typically performed by licensed electricians, pipefitters, or mechanical contractors working on overhead support systems. Ensure the beam flange is free of debris and within the clamp's jaw capacity before tightening. Follow applicable codes including NEC and local mechanical codes for support spacing and load requirements. Always verify the structural beam's rated load capacity before applying suspended loads to the clamp.

Technical Specifications

• Material: Malleable Iron
• Finish: Electroplated
• Base Width: 1 inch
• Base Depth: 1.25 inches
• Threaded Rod Size: 1/4 inch
• Weight: 0.188 pounds

Standard Information

• Brand: HALEX
• Manufacturer Part Number: 35600
