Halco 84081 T5HO LED Lamp 25W (45.2 in) T5FR25/850/DIR2/HO/LED

Product Description

Halco 84081 is a 25W T5HO LED tube engineered as a direct-fit retrofit for fixtures using program-start T5HO ballasts. The ballast-dependent lamp produces approximately 3,500 lumens at 5000K with a 270 degree beam spread and a rated life of 50,000 hours. The 45.2 inch frosted glass tube uses a G5 miniature bi-pin base, is non-dimmable, UL listed and DLC qualified, and is suitable for damp locations and totally enclosed luminaires.

• Plug-and-play ballast compatible with program-start T5HO ballasts (UL Type A; ballast dependent)
• Produces ~3,500 lumens from 25 W with 50,000-hour rated life and 270 degree beam angle
• G5 miniature bi-pin base, 45.2 in length, frosted glass; non-dimmable; suitable for enclosed fixtures and damp locations

Product Highlights

Ballast-compatible 25W T5HO LED tube (45.2 in) producing 3,500 lm, 50,000-hour life, UL Listed and DLC Qualified.

Product Information

Standard Information

• Brand: HALCO
• Manufacturer Part Number: 84081

Technical Specifications

• Brand: HALCO
• Manufacturer Part Number: 84081
• Model Number: T5FR25/850/DIR2/HO/LED
• Light Source Type: LED
• Wattage: 25 W
• System Wattage: 28 W
• Equivalent Wattage: 54 W
• Lumens: 3,500 lm
• Lumens per Watt: 140 lm/W
• Color Temperature: 5000 K
• Color Rendering Index (CRI): 82
• Rated Life: 50,000 hours
• Beam Angle: 270 degrees
• Base Type: G5 (Miniature Bi-Pin)
• Length: 45.2 in (4 ft)
• Diameter: 0.69 in
• Material: Glass
• Lens / Finish: Frosted
• Ballast Compatibility: Program-start T5HO ballast compatible (plug-and-play); ballast dependent (UL Type A)
• Replaces: F54T5HO (54 W fluorescent)
• Dimmable: No
• Listings / Certifications: UL Listed; DLC Qualified; RoHS Compliant; FCC
• Power Factor: >0.9
• Total Harmonic Distortion (THD): <20%
• Operating Temperature: -4 F to 122 F (-20 C to 50 C)
• Application: Suitable for damp locations and totally enclosed luminaires; area/general and high-bay lighting
