Hager Hinge RC127931226D14 Full Mortise Hinge Satin Chrome

Product Description

The HAGER HINGE RC127931226D14 is a full mortise, standard weight, plain bearing hinge designed for commercial and residential door installations. Measuring 3.5 inches by 3.5 inches with a 0.25-inch radius corner, this hinge installs flush into mortised cutouts on both the door and frame. The satin chrome finish provides a clean, neutral appearance suited to interior applications. Plain bearing construction makes this hinge appropriate for standard-frequency doors that do not require the added durability of ball or oil-impregnated bearings. The unit ships individually and is a staple product for door hardware contractors and finish carpenters who need a reliable, code-appropriate mortise hinge.

This hinge is used in full mortise door applications where the hinge leaf is recessed into both the door edge and the door frame. Standard weight sizing makes it appropriate for interior passage doors in residential and light commercial settings. It is commonly installed by carpenters, door hardware installers, and general contractors during new construction or renovation work. The satin chrome finish coordinates with brushed metal hardware families widely used in office, hospitality, and multi-family residential projects.

Key Features

• Full mortise design — both leaves recess into door edge and frame for a flush, clean installation
• 3.5 x 3.5 inch leaf size with 0.25-inch radius corners
• Plain bearing construction suited for standard-frequency interior doors
• Standard weight classification for typical passage door loads
• Satin chrome finish for a brushed, neutral appearance
• Sold individually, with a case quantity of 100 units available

Compatibility

Designed as an OEM-style replacement or new-installation hinge for standard full mortise door preparations accepting a 3.5 x 3.5 inch hinge leaf with 0.25-inch radius corners.

Installation Notes

Installation is typically performed by a licensed carpenter or door hardware installer using a router or chisel to prepare the mortise on both the door edge and the frame. Ensure the door is properly supported and the opening is square before scribing and cutting mortise pockets. Follow local building codes regarding hinge quantity per door leaf based on door height and weight. Do not over-drive fasteners into the hinge leaf countersinks, as this can distort the leaf and affect door swing.
