Hager Hinge 1751410R Full Mortise Spring Hinge Antique Bronze

Product Description

The HAGER HINGE 1751410R is a full mortise residential spring hinge finished in matte antique bronze. It measures 4 inches x 4 inches with a 1/4 inch radius corner profile and is constructed from steel. The spring mechanism provides automatic door return, making it suitable for doors that must remain closed by default. Licensed contractors, door hardware installers, and finish carpenters install this hinge when the application requires a self-closing function with a traditional mortise-style mount. The matte antique bronze finish delivers a consistent appearance across residential door hardware sets.

This hinge is intended for residential interior and exterior door applications where a spring-loaded self-closing hinge is required. Full mortise installation recesses the hinge leaf into the door edge and frame, producing a flush, clean fit. It is well suited for passage doors, utility room doors, and any residential opening that requires controlled, automatic closure. The 1/4 inch radius corner matches standard mortise pocket routing on most residential door blanks. Must be ordered in multiples of 2.

Key Features

• Spring-loaded mechanism provides automatic door return without a separate closer
• Full mortise design mounts flush with door edge and frame for a clean finish
• 4 inches x 4 inches leaf size suits standard residential door thickness and width
• 1/4 inch radius corners match common residential mortise pocket routing
• Steel construction provides durability in daily residential use
• Matte antique bronze finish coordinates with period and transitional hardware styles

Compatibility

Designed as an OEM-style replacement or new-installation spring hinge for standard residential full mortise door applications requiring a 4 inch x 4 inch hinge with 1/4 inch radius corners.

Installation Notes

Installation is performed by a licensed finish carpenter, door hardware installer, or general contractor. The door and frame must be mortised to the correct depth before hinge seating. Tension on the spring mechanism should be adjusted using the supplied tension pin before the door is hung. Always ensure the door is properly supported and the opening is plumb and square before final fastening.
