Gws 120992 Corner Radius End Mill 3/8 in 5 Flute Carbide

Product Description

The GWS 120992 is a solid carbide corner radius end mill engineered for demanding roughing and finishing operations in metalworking environments. It features a 3/8-inch cutting diameter with a 0.015-inch corner radius, five flutes, and a variable helix and variable index geometry that reduces harmonic chatter during aggressive cuts. The short-length design offers a 5/8-inch length of cut and 2-inch overall length, keeping the tool rigid in confined setups. The FX1 coating and submicron carbide grade support performance across a range of hard and abrasive workpiece materials. Machinists and toolroom operators use this end mill in CNC milling centers and manual mills for precision profile and pocket work.

This end mill is suited for shops running steel, cast iron, stainless steel, superalloys, titanium, and hard materials. The centercutting design allows plunge entry, making it adaptable to slotting, ramping, and helical interpolation strategies. The straight cylindrical shank with h6 tolerance mounts securely in standard end mill toolholders used in production and job-shop environments. The single-end configuration keeps tool management straightforward on high-volume runs.

Key Features

• 3/8-inch cutting diameter with 0.015-inch corner radius for edge protection and surface finish
• Five-flute geometry supports higher feed rates compared to four-flute designs in finishing passes
• Variable helix and variable index design reduces chatter in difficult setups
• Centercutting capable - supports plunge, ramp, and helical entry
• Submicron solid carbide grade with FX1 coating for extended tool life in hard and abrasive materials
• Right-hand cut, right-hand spiral flute direction for standard CNC and manual mill use

Compatibility

Designed for use with standard end mill toolholders. Primary workpiece materials include steel, cast iron, superalloys, titanium, and hard materials; secondary material is stainless steel. Part of the GWS Series 1035 short-length end mill line.

Installation Notes

Installation should be performed by a qualified machinist following the toolholder manufacturer's clamping specifications. Power down and lock out the spindle before changing tooling. Confirm shank seating depth and runout with a dial indicator before beginning a cut. Do not exceed the toolholder's rated speed or overhang the shank beyond recommended guidelines, as this can compromise rigidity and tool life.
