Guhring 9038660060000 Square End Mill 6mm 2 Flute Carbide

Product Description

The GUHRING 9038660060000 is a solid carbide square end mill engineered for precision milling in demanding machining environments. With a 6 mm cutting diameter and a 12 mm length of cut, this two-flute end mill delivers clean, accurate results in profiling, slotting, and light-to-medium material removal operations. The tool features a TiAlN coating that extends tool life by resisting heat buildup at the cutting edge during high-speed or dry machining. The 30-degree helix angle promotes efficient chip evacuation and reduces cutting forces. At 100 mm overall length with a 6 mm shank diameter, it fits standard collet toolholding systems used on CNC machining centers and manual mills. Licensed machinists and toolroom technicians are the primary users of this end mill.

This end mill is suited for use in CNC machining centers, vertical mills, and similar machine tools where tight tolerances and surface finish quality are required. The solid carbide construction and TiAlN coating make it appropriate for cutting ferrous and non-ferrous metals, hardened steels, stainless, and similar materials common in production and job-shop environments. The long-series profile provides additional reach for deeper cavity work without requiring extended-reach toolholders. It is a single-end tool from the GUHRING Series 3866 product line.

Key Features

• 6 mm cutting diameter with 12 mm length of cut for consistent depth control
• TiAlN coating improves heat resistance and extends tool life in high-speed applications
• 30-degree helix angle promotes smooth cutting action and efficient chip flow
• Solid carbide construction provides rigidity and dimensional stability
• Right-hand cut and right-hand flute spiral for standard spindle operation
• Long-series length at 100 mm OAL for added reach in deeper workpiece features

Compatibility

Designed as an OEM-specification solid carbide square end mill from GUHRING Series 3866, compatible with standard collet chucks and shrink-fit holders accepting a 6 mm shank diameter.

Installation Notes

Installation requires a properly sized collet or toolholder accepting a 6 mm shank; verify runout before production use. Ensure the machine spindle is fully stopped and the toolholder is de-energized before changing tooling. Consult machine tool documentation and applicable shop safety procedures for correct clamping torque on collet nuts. Inspect the cutting edges for chipping or coating wear before each use.
