Guhring 9037230060000 Corner Chamfer End Mill

Product Description

The GUHRING 9037230060000 is a solid carbide corner chamfer end mill engineered for precision chamfering and edge-breaking operations on ferrous and non-ferrous workpieces. With a 0.2362-inch cutting diameter, a 0.5118-inch length of cut, and a 0.3-inch chamfer width, this four-flute tool is built for controlled material removal in tight geometries. The FIREX coating provides thermal resistance and extended tool life in demanding cutting environments. At 0.02 pounds, it is a compact, high-precision tool suited to CNC machining centers and manual milling operations where edge quality and dimensional accuracy are critical.

This end mill is intended for use in metalworking applications requiring consistent chamfer profiles on part edges, countersink preparation, and deburring. Its regular-length configuration and 6 mm shank diameter make it compatible with standard collet systems on vertical machining centers and milling machines. The right-hand cutting and right-hand helical flute geometry promotes chip evacuation in typical climb and conventional milling passes. It is sized for small-diameter work common in precision machining, tool-and-die, and aerospace component production.

Key Features

• Solid carbide construction for rigidity and wear resistance in high-speed cutting
• FIREX coating for elevated thermal protection and reduced tool wear
• 0.3-inch chamfer width for consistent, defined edge profiles
• Four helical flutes with right-hand cutting direction for efficient chip flow
• 6 mm shank diameter compatible with standard ER and similar collet systems
• Compact regular-length body suited to close-tolerance milling fixtures

Compatibility

Designed as an OEM-style solid carbide chamfer end mill for use in CNC vertical machining centers and manual milling machines equipped with collet or end mill holders accepting a 6 mm shank diameter.

Installation Notes

Installation should be performed by a qualified machinist or CNC setup technician. Ensure the spindle is fully stopped and the machine is in a safe, locked-out state before changing tooling. Verify collet size matches the 6 mm shank and torque the collet nut according to the collet system manufacturer's specification. Inspect the cutting edges for chips or coating damage before use, and confirm runout is within acceptable tolerance for the intended application.
