Guden 2000300918 Concealed Hinge 3 in Stainless Steel 316

Product Description

The GUDEN 2000300918 is a concealed hinge manufactured from grade 316 stainless steel. It is designed for applications where the hinge mechanism is hidden from view when the door or panel is closed, providing a clean, flush appearance. With an overall width of 3 inches and a leaf thickness of 0.09 inches, this hinge offers a low-profile footprint suited to enclosures, cabinetry, and panel installations. The 0.187-inch pin diameter delivers consistent pivot performance. At 0.285 pounds, it is lightweight without sacrificing structural integrity. Installation is typically handled by millworkers, enclosure fabricators, or maintenance technicians working on equipment panels and cabinet assemblies.

This hinge is suited for light- to medium-duty concealed installations in both commercial and industrial environments. Grade 316 stainless steel provides elevated corrosion resistance, making it appropriate for marine, food-service, chemical-adjacent, or outdoor-exposed enclosure applications where a standard 304-grade hinge would be insufficient. Typical use cases include electrical enclosure doors, instrument panels, cabinetry, and cleanroom or washdown environments where exposed hardware must be minimized.

Key Features

• Grade 316 stainless steel construction for superior corrosion resistance
• Concealed design hides hardware when door or panel is in the closed position
• 3-inch overall length and 3-inch overall width for consistent coverage
• Leaf thickness of 0.09 inches for a low-profile, flush-mount fit
• Pin diameter of 0.187 inches for stable, repeatable pivot action
• Lightweight at 0.285 pounds, minimizing added load on door or panel

Compatibility

Designed as an OEM-style concealed hinge replacement or new-installation component for doors, panels, and enclosures requiring a 3-inch stainless steel concealed hinge with a 0.09-inch leaf thickness.

Installation Notes

Installation is typically performed by millworkers, enclosure fabricators, or qualified maintenance technicians. Power down any electrical enclosure fully before servicing doors or panels. Ensure mounting surfaces are clean and flat before fastening to maintain proper alignment and full leaf contact. Use fasteners appropriate for grade 316 stainless steel to avoid galvanic corrosion at the mounting point.
